New Alamto Eco Series 3 Ton Forklift
Alamto Eco Forklift
- Model: Port Plus 3
- Brand: Alamto
- Fuel Type: Diesel
- Capacity of Loading: 3 Ton
- Mast Type: Triplex Full Free Mast
- Max Lifting Height: 3 m
- Load Center: 500 mm
- Tyre: pneumatic Tyre
Rated Load Capacity
3,000 kg
Maximum Lift Height
3,000 mm
Engine Type
Diesel
New Alamto Eco Series 3 Ton Forklift
Model: Port Plus 3 Brand: AlamtoYear of Manufacture: 2025 Fuel Type: Diesel Capacity of Loading: 3 TonMast Type: Triplex Full Free MastMax Lifting Height: 3 mLoad Center: 500 mmTyre: pneumatic Tyre Transmission: AutomaticMax Gradeability (Loaded): 20%Free lifting Height: 150 mm Turning Radius: 2395mm Overall Length (with Fork): 3800 mm Overall Width: 1240 mmOverhead Guard Height: 2145 mmFork Size (LxWxT): 1220x125x45 mmMast Height (Fork Lowered): 2140 mm Battery (Voltage/capacity): 12/90 V/AhTruck Weight: 4250 kg Engine: Xinchai C490 Power of Engine: 40kw Number of Cylinders: 4
New Alamto Eco Series – Port Plus 3 Ton Diesel Forklift
Designed for efficiency and durability, the Alamto Eco Series Port Plus 3 is the perfect choice for Dubai’s busy warehouses, ports, and industrial operations. Built with a robust Triplex Full Free Mast offering a 3 m lift height and 500 mm load center, this forklift ensures optimal handling and stability, even on challenging terrain.
Powered by a 40 kW Xinchai C490 diesel engine, automatic transmission, and pneumatic tires, the Port Plus 3 delivers smooth operation with a max gradeability of 20% under full load. Its compact turning radius of 2395 mm allows efficient maneuvering in tight spaces, while the sturdy overhead guard and free lift height of 150 mm provide enhanced safety for operators.
Key dimensions include an overall length of 3800 mm (with fork), width of 1240 mm, and mast height of 2140 mm when lowered. The 12V/90Ah battery ensures reliable accessory power, and the heavy-duty build (4250 kg total weight) guarantees long-lasting performance in demanding GCC environments.
The Alamto Eco Series is built to meet Dubai’s industrial needs—offering reliability, strength, and precision in every move.
| Specifications | Operating weight（kg） | Bucket capacity（m³） | Engine&Rated power（kw/r/min） |
| 1940 | 0.04 | YANMAR：10.3/2200 YANMAR：11.2/2400 YANMAR：14.1/2400 | |
| Overall Dimension | Overall length（mm） | Overall width（mm） | Overall height（mm） |
| 3867 | 990-1320 | 2313（1185） | |
| Working Range | Max. dumping height（mm) | Max. digging height（mm) | Max. digging reach（mm） |
| 2323 | 2110 | 3900 |
